12V 28Ah sealed lead acid battery

TLA12280T-KL

12V 28Ah sealed lead acid SLA  battery supply by UNICELL in Singapore

TLA12280T-KL (28Ah replace the 24Ah old series )Categories:      12V 28Ah Sealed Lead Acid (SLA) maintenance free battery,
Description:     12V rechargeable battery
Size:                Length 165 x Width 125 x Height 175 mm (with terminal) + 2mm
Weight:            9.2 Kg
Terminal:         M5 screw )
Application:     UPS, Exit light , back-up system
Specifications
  • Cells Per Unit: 6
  • Voltage Per Unit: 12 V
  • Capacity: 26.0Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)
  • Weight (kg): Approx. 9.2kg
  • Maximum Discharge current (A): 280A (5sec.)
  • Internal Resistance Approx.: Approx. 9mΩ
  • Operating Temperature Range:
    - Discharge:-15~50(5°F~122°F)
    - Charge:-15~40(5°F~104°F)
    - Storage:-15~40(5°F~104°F)
  • Nominal Operating Temperature Range: 25°C ± 3°C (77°F ± 5°F)
  • Float charging voltage: 13.5 to 13.8 VDC/unit Average at 25°C (77°F)
  • Recommended Maximum Charging current limit: 8A
  • Equalization and Cycle Service: 14.4 to 15.0 VDC/unit Average at 25°C (77°F)
  • Self Discharge: Unicell batteries can be stored for more than 6 months at 25°C (77°F)
    Please charge batteries before using. For higher temperatures the time interval will be shorter.
  • Container Material: ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request.
Fits UPS Models or battery cross refer part no.
Fit or replace battery part no. (Cross refer or compatible chart )
ABB Totalflow 2015052-001 rev AQ battery (W28008-1514)
Anda Olsen NH12-120W battery
C&D UPS12-100MR battery
CSB 12V 30Ah battery
CSB EVX12300 battery
CSB GPL12280 battery
CSB HR12120W battery
CSB HRL12110W battery
CSB HRL 12110W battery 12V 110W
CSB HRL 12110WFR battery
CSB HRL12110WFR battery (12V 27Ah)
CTM CTL 28-12 battery
Deka ETX30LA battery
Douglas Guardian DBG12-28NB battery
Douglas Guardian DBG1224J battery
Douglas Guardian DG12-28NB battery
Douglas Guardian DG1224J battery
Dynasty UPS 12-100 battery ( C&D Technologies Inc. )
Eaton 12V 120W PWHR12120EFR battery
Eaton PWHR12120W3FR battery
EnerSys NPX-100BFR battery
Enersys G26EP battery
Enersys XE30 battery
EnerSys NPX-100B battery
EnerSys 12V 28Ah battery
EnerSys NPX-100R battery
EnerSys 12V 24Ah battery
Exide EP26-12W battery
Firstpower FP12240A battery
Firstpower FP12280A battery
Genesis G12V26AH battery
Genesis NPX-100BFR battery
Genergy NH12-120W battery
GNB L12V24 battery - NALL120024HM0MA
GS Storage PWL12V28 battery
GS Yuasa PWL12V24 battery
Hawker Cyclon 12V 30Ah battery
Hawker Cyclon 12GA30 battery
Haze HZB12-28 battery
Hitachi HP28-12W battery
IBT BT26-12 battery
IE Industrial Energy IE 12240A battery
IE Industrial Energy IE 12280A battery
Interstate PC12280 battery
Long WP30-12T battery
Long WP28-12 battery
Long WP30-12TN battery
Long WP26-12T battery
Marathon M12V30T battery
Marathon L12V24 battery
MK ES28-12 battery
MK ES30-12 battery
Neuton Power NP12260H battery
Neuton Power NP1228H battery
Odyssey PC925 battery
Panasonic LC-X1224APG battery
Panasonic LC-X1228P battery
Panasonic LC-X1228AP battery
Panasonic LC-XC1228P battery
Panasonic LC-XB1228 battery
Panasonic LC-XB1228AP battery
Panasonic LC-XB1228P battery
Panasonic LC-XC1228AP battery
Panasonic LC-XC1228P/PA battery
Panasonic 12V 26Ah battery
Powec A/S LC-Xb1228AP battery (RU 291 A 0159 )
Power Patrol SLA1152 battery
Power-Sonic PS-12280 battery
Powersonic PS-12280 NB battery
Power-Sonic PHR-12100 battery
Bombardier Sea-Doo GTX 4-tec battery ( RXP years 2003 to 2007 )
Rocket ES26-12FR battery
Tempest TD28-12A battery
Tempest TR28-12 battery
Tripp Lite BC 750LAN-2 battery
Vision CP12280S battery
Vision HF12-155W FR battery
Xupai 6-DZF-32 battery (12V 32Ah)
Yuasa NP26-12B battery
Yuasa NPX-100R battery ( Flat terminal )
Yuasa NPX-100B battery
Yuasa NPX-100BFR battery
Yuasa NPX100RFR battery
6FM28 battery
UPS12-100MR

Disclaimer: The products supplied by our Company are [replacement for] sold for use with certain products manufacturers, and any reference to products or trademarks of such companies is purely for the purpose of identifying the computers with which our products [are replacement for] may be used. Our Company and this Web site are neither affiliated with, authorized by, licensed by, distributors for, nor related in any way to these computer manufacturers, nor are the products offered for sale through our web site manufactured by or sold with the authorization of the manufacturers of the computers with which our products [are replacement for] may be used.
